Layout & Measuring

3" Digital Protractor

The Wixey Digital Protractors can be used in any plane.

• 0.1 degree resolution, accuracy, and repeatability
• Sets both miter and bevel angles on almost any machine
• Strong magnets on all blade edges for ease of use
• Blades can be tightened for holding measurements
• 2" wide X 7/8" thick X 4" long
• Compact design for tight locations
• Sets miter saw miter and bevel angles
• Great for drill press and band saw tables

8" Digital Protractor

The Wixey Digital Protractors can be used in any plane.

• 0.1 degree resolution, accuracy, and repeatability
• Sets both miter and bevel angles on almost any machine
• Strong magnets on all blade edges for ease of use
• Blades can be tightened for holding measurements
• 2" wide X 7/8" thick X 9" long
• Long legs for added versatility
• Measure work-piece or construction angles
• Use for marking and layout

Digital Angle Rule 500mm

Two x 18-1/2 inch (960mm) rule digital angle rule that calculates angles quickly and accurately and is ideal for woodworking, construction, and machining.

Features:

• Digital display for angles.
• Stainless steel rule with metric/imperial scale, scale length 500mm and 18-1/2 inch.
• Measuring range from 000.0 deg to 360.0 deg, with accuracy of 0.3 deg.
• Rule locking function.
• Easy operation with two press buttons.
• Auto-shut off in 6 minutes.

Digital Angle Protractor with Rule

This digital protractor/rule allows you to precisely set and measure angles in 0.05 degree increments. The stainless steel arms are graduated inch and metric scale for convenient and immediate linear measuring. Features a hold function, ensuring you never lose your reading, and a reverse reading capability for those hard to calculate angles. The protractor measures angles from 0 to a full 360°. Packaged in a protective plastic pouch with an extra battery.

Protractor

This new style protractor can measure, mark and transfer any angle ...inside, outside, barred angle and slope angle ...under 90 degrees or over 90 degrees. It's ideal for fitting dollhouse siding to roof angles, setting table saw and disk sander angles, gauging model railroad slopes, measuring ship model mast rake angles, model airplane dihedral and hundreds of other uses. Made of high impact plastic with knurled brass locking nut. Longest blade is 6 inches long. Winner of Switzerland's Gold Award for new inventions. Instructions included.

6" Precision Marking Protractor

The Incra 6-Inch Precision Marking Protractor lets you plot any angle with ease and absolute accuracy. A metal T-Bar and see-through cross hairs provide perfect alignment against the edge of your work-piece. Remove the T-Bar to work on flat surfaces or to use the 6-inch centering scale with micro-fine marking holes at every 1/32 inches. This marking protractor has micro-fine guide holes at every 45-, 30-, 22.5-, 5-, 1-, and 0.5-degree intervals. Four angle scales, including one for marking narrow stock, suit every need. Its easy on the eyes, incredibly accurate, and just plain fun to use.

• Protractor lets you plot any angle with ease and absolute accuracy
• T-Bar and see-through crosshairs provide perfect alignment
• 6-inch centering scale with micro-fine marking holes at every 1/32 inches
• Four angle scales, including one for marking narrow stock
• Micro-fine guide holes at every 45-, 30-, 22.5-, 5-, 1-, and 0.5-degree intervals

Digital Angle Finder

Digital angle finder 8 inch (200mm) with level vial.

Features:

• Large clear LCD display with digital readout to allow easy reading of angles.
• Calculates angles from 0-220 degrees. Up to 360 degrees when locking knob removed. Resolution of 0.05 degree.
• Large aluminum stock for stability and accuracy.
• Robust but lightweight aluminum construction butt.
• Dual metric/imperial scale folding metal blade 50mm wide with locking function.
• Use on internal and external angles to quickly measure an angle saving time and money.
• Use to check saw blade angle to bed.
• Easy operation with three buttons on/off, hold and zero/ABS.
• Readout always reads correctly when used in ABS mode.
• Spirit level vial
• Hold function.
• 90 degree angle check on end of blade.
• Auto-shut off in 5 minutes.

Multi-Mark
Multi-Purpose Marking and Measuring Tool

The Kreg Multi-Mark (model KMA2900) is an incredibly handy multi-purpose marking and measuring tool, perfect for a wide variety of household and jobsite applications.
›See more product details

×

Multi-Mark Multi-Purpose Marking and Measuring Tool

The Kreg Multi-Mark (model KMA2900) is an incredibly handy multi-purpose marking and measuring tool, perfect for a wide variety of household and jobsite applications. The Multi-Mark features three different scale configurations, a built-in level, a handy 3/16-inch reveal gauge, and much more. Whether you need to transfer a measurement for that last ceramic tile, layout some mitered corners, or just straighten a few simple picture frames, the Multi-Mark is the only tool you'll need to get the job done.

One Tool Does it all

• Layout Mitered Corners
• Set 3/16" Reveals
• Transfer Measurements
• Align / Square Your Projects
• Set Bit / Blade Heights
• Layout Wall Studs
• Use as a Basic Rule
• Marking for Layout
• Use as a Simple Level
• 3-Way Adjustable Rule
• Imperial and Metric Scale
• Compact Design
• Layout Tool
• Trimming Tool
• T-Square
• Depth Gauge
• Torpedo Level
• Story Stick

Close

One Tool Does it all

• Layout Mitered Corners
• Set 3/16" Reveals
• Transfer Measurements
• Align / Square Your Projects
• Set Bit / Blade Heights
• Layout Wall Studs
• Use as a Basic Rule
• Marking for Layout
• Use as a Simple Level
• 3-Way Adjustable Rule
• Imperial and Metric Scale
• Compact Design
• Layout Tool
• Trimming Tool
• T-Square
• Depth Gauge
• Torpedo Level
• Story Stick

Digital Bevel Box

Take the guesswork out of setting up those critical bevel cuts on your table saw, jointer, bandsaw or drill press table. Just set the unit on a flat reference surface, press the ZERO button to calibrate the display then attach it to the saw blade, fence, etc. and precisely adjust to the desired angle. The Angle Cube offers 0.2° accuracy with a resolution of 0.05° at a range of 90°. The large LCD screen makes it easy to read while strong magnets hold the unit to any steel or cast iron surface. Spare battery included, measures 2 3/8" x 2 3/8" x 1 3/8".

Features:

• 0.2° accuracy with a resolution of 0.05° at a range of 90°
• Large and easy to read LCD screen
• strong magnets hold the unit to any steel or cast iron surface
• Measures 2 3/8" x 2 3/8" x 1 3/8"
• Spare battery included

Perfect Butt

Trend's 'Perfect Butt' is a simple yet ingeniously elegant solution to an awkward problem faced by many woodworkers, tradesmen's & enthusiasts - scribing in work surfaces, floor & shelving etc. into awkward or oddly shaped areas. It quickly and accurately scribes profiles to ensure a perfect join between two uneven work pieces, every time.

Features:

• Quick & easy to use
• Sprung loaded pencil for consistent scribe contact
• Remains stable whilst scribing
• Profiles single surfaces & complete areas
• Minimize material wastage & costs

Includes:

• 1 ea. Trend Perfect Butt

MS/PRO 15-Function Multiscribe Profile Matching Tool

The Trend Multiscribe is a multi-function profile matching tool that is used to transfer contours from one shape to another and mark on various materials. For use by all trades, carpenters, joiners and builders, the Multiscribe may be used as a compass, plumb bob, vertical or horizontal level. Steel blade is graduated with 1/4" and 5mm for profiling and features a built-in spirit level and pencil sharpener.

Features:

• 15 Functions
• Parallel, convex, concave and contour scribe
• For all trades
• Built in level vile and pencil sharpener
• Steel blade with 3/16-Inch and 1/4-Inch graduations

Square N Tape™

No need to use a builder's square or chalk box; using the peel and stick backing, simply attach SquareNTape™ to any standard tape measure (sold separately) then slide and mark your board with the 8-in-1 SquareNTape™ from FastCap®! SquareNTape™ features include a 90° squared edge that lets you lay it across a board for 90° squaring capabilities. Notches at 1-1/2" and 3-1/2" make it easy to mark 2" x 2" and 2" x 4"s out of wide construction boards. Made in USA.
›See more product details

×

Square N Tape™

No need to use a builder's square or chalk box; using the peel and stick backing, simply attach SquareNTape™ to any standard tape measure (sold separately) then slide and mark your board with the 8-in-1 SquareNTape™ from FastCap®! SquareNTape™ features include a 90° squared edge that lets you lay it across a board for 90° squaring capabilities. Notches at 1-1/2" and 3-1/2" make it easy to mark 2" x 2" and 2" x 4"s out of wide construction boards. SquareNTape™ also has marks at 1-1/2" and 3" for laying out plates for single and double stud layouts; perfect for window and door construction. Marks at 45° and 22-1/2° make it easier to mark angled lines, plus, it has a handy erasable notepad for writing down measurements. Made in USA.

Technical Details:

• Eliminates the need for a builder's square or chalk box
• 90° squared edge lets you lay SquareNTape™ across a board for 90° squaring capabilities
• Squared edge also lets you mark and slide using notches at 1-1/2" and 3-1/2" - ideal for marking door and window plates for single and double stud layouts
• Marks at 45° and 22-1/2° for marking angles
• Handy erasable notepad eliminates the chance you'll forget important measurements
• Made in USA

Close

• 90° squared edge
• Squared edge also lets you mark and slide using notches at 1-1/2" and 3-1/2"
• Marks at 45° and 22-1/2° for marking angles
• Handy erasable notepad
• Made in USA
