Table Saws & Accessories

×

17” NoPlay Aluminum Miter Bar

Once installed, you can easily adjust and calibrate the NoPlay miter bar from above on your sled! NoPlay Miter Bars are designed to be adjusted to fit your table saw, router table or band saw miter slot. Simply set it, test it and make any needed adjustments for the ideal fit. Each miter bar comes with a transparent stick-on template making installation a breeze! Can be mounted using the included wood screws that secure the bar through the bottom of your sled. Alternatively you can use the included machine screws to mount the bars through the top of your sled.

Designed for Use in any Standard 3/4” x 3/8” Miter Slot

The NoPlay Miter bar is designed for use in any standard 3/4” x 3/8” miter slot. Made from aluminum, the bar will not bow or warp like some plastic or wood bars do. Will work in many router table and band saw slots. Excellent for crosscut sleds on your table saw!

One of a Kind Expandable Glides

The one of a kind Expandable Glides (Patent Pending) are designed expand or contract as you tighten or loosen the center screw. Rotating clockwise expands the Expandable Glide while rotating the counter-clockwise contracts/brings the Expandable Guide back toward the miter bar.

×

18" Precision Steel Miter Bar

Build your next table saw sled, router table jig or band saw fixture to operate with a smooth sliding action using the Fulton 18 inch Precision Steel Miter Bar! Attach the steel bar to most any type of sled, jig or fixture that is to be used with a 3/4 inch (19mm) by 3/8 inch (9mm) miter slot. Using our steel bar versus plastic or aluminum gives your sled, jig or fixture more strength and stability and it won't bend or warp.

When building sleds, jigs and fixtures one of the most important aspects is to achieve a smooth sliding action without side to side play. The Fulton Precision Steel Miter Bar does both with its solid steel bar and 4 adjustable spring loaded plungers. The plungers can be adjusted with the included hex key wrench for just the right fit.

18" Long Steel Miter Bar for 3/4" x 3/8" Miter Slots

The Fulton 18" Steel Miter Bar is the perfect size for many of the jigs and fixtures we build for our table saws, router tables and even band saws. It's not oversized like many of the other bars that are available. This bar perfect for mounting on your next shop built sled, jig or fixture for a smooth run though the blade or cutter every time!

A Definite Upgrade

When compared to plastic UHMW bars or even light duty aluminum miter bars, the Fulton Steel Miter Bar stands above the rest. With its sturdy, solid steel construction, this bar will not prevent warping or bending, it provides a consistent smooth run through your cutter or blade. Over time, plastic and even aluminum can bend to the will of the wood platform. Our steel miter bar is designed to resist warping or bending and will last for years. This, more importantly allows for a smooth running jig, sled or fixture since you know it won't expand or contract like other bars typically do.

Two is (just may be) Better Than One...

Depending on your project, you may need to have two runners or miter bars on the underside of your platform. The larger the sled, jig or fixture, the more likely you will need to do this. This also depends on the machine you are building your project for. Smaller table saws may only have one slot.

T-Slot Compatible

The Fulton 18" Steel Miter Bar fits neatly into standard 3/4" x 3/8" miter T slots that are commonly found on may table saws, router tables and band saw table tops.

U Shaped Slot Compatible

The Fulton 18" Steel Miter Bar fits neatly into standard 3/4" x 3/8" miter U Shaped slots that are commonly found on may table saws and other workshop machinery.

Top Down or Bottom Up Installation

Unlike other "adjustable" plastic or aluminum miter bars, the Fulton 18" Steel Miter Bar can be mounted from the top down or you can mount it from the bottom upwards. This makes this miter bar even more versatile and provides you with the flexibility of not being stuck drilling into the top of your freshly built sled, jig or fixture. Wood screws and machine screws NOT included.

Fulton 18" Steel Miter Bar Specifications

Each device in this set is made from a super durable polymer plastic to stand up to everyday use. They are almost indestructible! Each of the blocks with foam pads are designed to grip the material. If they become built up with dust and debris, clean them with warm soapy water and let them dry for at least 24 hours before using them again.

Not only is the Fulton Steel Miter Bar adjustable, its easy to mount! You can mount the bar from the top of your sled, jig or fixture platform or base, or you can mount it from the bottom. There are three threaded holes along the length of the bar for mounting the bar using 1/4 inch by 20 tpi machine screws (not included). There are also three counter sunk holes on the bar to mount the bar using #8 wood screws (not included).

Once you mount the bars to your sled, jig or fixture you are sure to feel the difference. This is especially true when you first run the bars through your miter slots. The smooth sliding action is perfect for crosscut sleds, miter angle jigs, shop made coping sleds and a whole lot more! Using two bars (only one is included) for even more stability works exceptionally well.

The bar is approximately 18 inches long and will fit into miter t slots and u-shaped miter slots. Non-standard slots found on some job site style table saws and other small machinery will not accept this bar due to the non-standard slot dimensions. We recommend that you measure your miter slot before placing your order.

×

19" Precision Aluminum Miter Bar

Build your next table saw sled, router table jig or band saw fixture to operate with a smooth sliding action using our 19 inch Precision Aluminum Miter Bar! Attach the aluminum bar to most any type of sled, jig or fixture that is to be used with a 3/4 inch (19mm) by 3/8 inch (9mm) miter slot. Using our aluminum bar versus plastic or wood gives your sled, jig or fixture more strength and stability and it won’t bend or warp.

When building sleds, jigs and fixtures, one of the most important aspects is to achieve a smooth sliding action without side to side play. The 19 inch Precision Aluminum Miter Bar does both with its solid aluminum bar and 5 adjustable spring loaded plungers. The plungers can be adjusted with the included hex key wrench for just the right fit.

19" Precision Aluminum Miter Bar for 3/4" x 3/8" Miter Slots

The bar is approximately 19 inches long and will fit into standard (3/4 x 3/8 inch) miter t slots and u-shaped miter slots. Non-standard slots found on some job site style table saws and other small machinery will NOT accept this bar due to the non-standard slot dimensions. We recommend that you measure your miter slot before placing your order.

Perfect for Shop Built Sleds, Jigs and Fixtures

The 19" Aluminum Miter Bar is perfect for shop built sleds, jigs, fixtures and more! Easy to mount and easy to adjust, the miter bar helps provide a smooth run through your miter slot. Add a second miter bar for larger sleds, jigs or fixture. Please note that only one miter bar is included.

2 Mounting Options

With the included wood screws and machine screws, you have 2 different mounting options. With the wood screws you simply align your miter bar, clamp it in place and attach the bar using the wood screws from the bottom. When mounting from the top, pre drill your holes, counter sink the holes and attach the bar using the machine screws.

Adjustable Spring Loaded Plungers

While the bar fits most 3/4" x 3/8" miter slots without much play, there may be some slots that are a little bit different. To adjust the plungers, use the provided hex key wrench to push the plungers outward. The plungers are spring loaded to give you just the right amount of sideways pressure for the perfect fit. Unlike other miter bars that use nylon or plastic set screws to snug up the bar, this bar uses steel plungers that will last much longer and perform much better.

Solid Aluminum Bar

Extruded aluminum bar for superior durability. The aluminum miter bar is lightweight and perfect for sleds, jigs and workshop fixtures since it does not add a considerable amount of weight and will not bend or warp like wood or plastic bars.

MEASURE your MITER SLOT

We ask that you measure the width and height of your miter slot before ordering as some slots vary and will not be compatible with our miter bar.

×

Steel Miter Slider IMS1SE (Special Edition)

The INCRA Miter Slider SE combines the versatility of the INCRA Build-It products with the unique performance and feel of the adjustable GlideLOCK miter bar used on INCRA miter gauges. Miter Slider SE is not recommended for stationary jigs that must be locked into position within a miter slot; choose standard aluminum Miter Slider for these applications. Steel bars are more rigid than wooden or plastic runners and are not susceptible to changes in humidity or temperature. Miter Slider SE bars have (4) #10-24 holes that mate with INCRA Build-It Panels. Miter Slider SE bars also have (3) 1/4"-20 holes along the length to accept knobs and other fasteners commonly used when building jigs and fixtures. Long-wearing Nylon GlideLOCK adjusting discs provide a precise fit in the miter slot of most table saws, router tables and band saws. Nylon GlideLOCK adjusting discs give the bars a smooth, low-friction travel. Bars include removable T-slot retaining clips for BOTH ends of the bar for superior stability of larger jigs. Miter Slider SE is compatible with all INCRA Build-It Panels. Miter Slider SE fits square-sided 3/4" x 3/8" miter slots with or without T-slot bottom. GlideLOCK adjustment for slots measuring 0.740" to 0.765" in actual width.

Features:

• Available in 2 sizes: 18" and 25.5"
• Super strong steel construction
• Adjusts for a perfect glide in any standard 3/4" x 3/8" miter channel
• Compatible with Build-It System panels or create your own custom jig designs

×

DIY Table Saw Crosscut Sled Kit

If you own a table saw, you probably have come across a situation or two where you need to make smaller cuts or make cross cuts. You may also have had the need to make repetitive cuts of the same length. Making small cuts, cross cuts and repetitive length cuts is where table saw crosscut sleds excel. Crosscut sleds help stabilize the work piece and are very accurate since they are essentially calibrated to your saw during the sled building process. Some time ago we noticed a lot of companies had UHMW bars available for purchase. While we as a woodworking company know exactly what they are used for, many novice or non-woodworkers do not. That's when we decided to create this package with pre-cut UHMW bars, pre-cut aluminum track, a knob and bolt and an easy to understand how to guide booklet so you can create your very own, custom crosscut sled to fit your table saw!

Why Make it Complicated

This kit has been put together with one main theme in mind. Keep it simple. From the hardware included, to the "How To" Guide Booklet, we made the crosscut sled building process a breeze. Sure, you can spend more money other kits to try and build a sled, but most of those kits and manufacturers assume you already have it all figured out. We chose the opposite approach and prepared everything for you and included everything but the wood material in this kit. Its as simple as taking the supplied hardware, choosing your size, then build your sled to your specifications!

Please Note: Wood and other building materials are NOT included with this kit.

Whats a Cross Cut Sled You Ask?

Crosscut sleds have a basic singular purpose and that is to crosscut smaller stock pieces on your table saw. Thats the basic function of a crosscut or cutoff sled. However, crosscut sleds are excellent for not only small stock pieces but mid size cuts as well. Not only that, these sleds can be used for making repetitive cuts at the same length when a stop block is employed. Crosscut sleds typically become one of the most commonly used jigs in your workshop.

Please Note: Wood and other building materials are NOT included with this kit.

High Quality Parts

From the UHMW bars to the Anodized Aluminum Tracks, this kit is made for the task and not to mention made in the USA! The track and UHMW bars are the perfect hardware to help you create and build the ideal crosscut sled.

Please Note: Wood and other building materials are NOT included with this kit.

Full Color, Full Detail How To Guide Included

When putting this kit together we wanted to make sure that we covered all the bases. The final piece of the puzzle was the How To Build Your Own Crosscut Table Sled guide booklet. We took the time to map out how to build your very own sled, but left the dimensions up to you so you can adapt the sled to your particular table saw.

Please Note: Wood and other building materials are NOT included with this kit.

Your Saw... Your Size

The size of the sled can be any basic size you require based on the size of your table saw. While most contractor and consumer level cabinet saws are 27" long from front to back, many job site saws are considerably smaller. The one thing you must make sure of is that the UHMW bars will fit into your slot. This kit includes 3/4" x 3/8" UHMW for standard 3/4" x 3/8" miter slots.

Please Note: Wood and other building materials are NOT included with this kit.

Please Note: Wood and other building materials are NOT included with this kit.

Made in the USA

Made in the USA so you know you're getting a high quality kit to help you with your next workshop project!

UHMW bars are most commonly used as runners for crosscut sleds since they don't produce as much friction as wood does. Another advantage is that UHMW won't expand or contract like wood does during drastic weather changes. Each bar is approximately 3/4" x 3/8" which fits most standard table saw slots. UHMW bars are also slick and won't leave any residue, dust or shavings behind like wooden bars tend to do. The tracks that are included in this kit are made from solid extruded aluminum and are Made in the USA. Each track is cut to length for the perfect sub-fence on the crosscut sled. The included knob and bolt is for making a simple stop block which when finished, can slide the length of either track along the sub-fence. The stop block will allow you to make repetitive cuts without having to constantly move and measure the fence distance each time you make a cut.

We have also included a full color and detailed how to guide book to help you with the crosscut sled building process. Each kit comes with 2 each 19" long by 3/4" by 3/8" UHMW bars, 2 each 12" long mini tracks, 1 each knob, 1 each 1/4" by 20 tpi bolt and a how to build your own crosscut sled guide book. Make your crosscut sled to the size you want or need for your table saw and your specific cutting needs.

Please Note, the bars do NOT FIT RYOBI table saw track slots.
